Doped Glue Heating Stirrer

Magnet Machinery VIEW []

TB Type Doped Glue Heating StirrerGeneral Description:This doped glue heating stirrer introduces Korean advanced technology, it is the mixing equipment dedicate

INQUIRY

TB Type Doped Glue Heating Stirrer

General Description:

This doped glue heating stirrer introduces Korean advanced technology, it is the mixing equipment dedicated to tungsten alloy, tungsten carbide, precious metal powder, non-ferrous metal powder, bonded magnets and other industries.

TB Type Doped Glue Heating Stirrer

Features:

  1. The stirrer works by rotating impeller in its cylinder body to make heated liquid dissolved slowly and coated to the surface of metal powder evenly
  2. With automatic lifting device, mixing from top to bottom can be adjusted at any time
  3. Two heating modes: oil heating and water heating
  4. Temperature can be controlled between 0℃ ~ 280℃ freely according to the user requirement
  5. The internal parts of cylinder which will contact materials are all adopting smooth transition design, no dead angle, can clean thoroughly, to avoid cross-contamination of materials

Technical Data:

Model Agitating vane
(r/min)
Agitating motor
(kw)
Lifter motor
(kw)
Max. Temperature
(℃)
Production Capability
(kg/time)
Outline dimension
L×W×H(mm)
Weight
(kg)
TB-20 0-60 0.4 0.2 280 20 930×670×1850 250
